FRONT FOG LAMP BULB, REPLACE
Refer to Fig. 1 for exploded view of fog lamp.
Caution: Halogen bulbs contain gas under pressure. Handling a bulb improperly could cause it to shatter into flying glass fragments.
Caution: To help avoid personal injury: Turn off the lamp switch and allow the bulb to cool before changing the bulb.
Caution: Leave the lamp switch OFF until the bulb change is complete.
Caution: Always wear eye protection when changing a halogen bulb.
Caution: Handle the bulb only by its base. Avoid touching the glass.
Caution: Keep dirt and moisture off the bulb.
Caution: Properly dispose of the used bulb.
Caution: Keep halogen bulbs out of the reach of children.
- Remove electrical connector, Fig. 1(see below).
- Remove bulb from rear fog lamp assembly by twisting bulb counterclockwise and pulling bulb out.
- Reverse procedure to install.
![2006 chevy silverado fog lamp explded view diagram](https://www.freeautomechanic.com/mechanic/forum/wp-content/uploads/2023/10/2006-chevy-silverado-fog-lamp-explded-view-diagram.jpg)
REAR FOG LAMP BULB, REPLACE
Refer to Fig. 2 for exploded view of rear fog lamp.
Caution: Halogen bulbs contain gas under pressure. Handling a bulb improperly could cause it to shatter into flying glass fragments.
Caution: To help avoid personal injury: Turn off the lamp switch and allow the bulb to cool before changing the bulb.
Caution: Leave the lamp switch OFF until the bulb change is complete.
Caution: Always wear eye protection when changing a halogen bulb.
Caution: Handle the bulb only by its base. Avoid touching the glass.
Caution: Keep dirt and moisture off the bulb.
Caution: Properly dispose of the used bulb.
Caution: Keep halogen bulbs out of the reach of children.
- Remove rear fog lamp lens (1) retaining screws (2), Fig. 2.
- Remove bulb from rear fog lamp assembly by twisting bulb counterclockwise and pulling bulb out.
- Reverse procedure to install.
![rear fog lights 2006 chevy silverado exploded view diagram](https://www.freeautomechanic.com/mechanic/forum/wp-content/uploads/2023/10/rear-fog-lights-2006-chevy-silverado-exploded-view-diagram.jpg)
